The recessed ceiling luminaire PANEL C 600 is designed for indoor installation and is particularly suitable for offices, administrative buildings, and similar environments. It features a square shape with dimensions of 59.5 x 59.5 cm and a slim installation depth of 2.8 cm. The housing is made of aluminium, ensuring a robust and durable construction. The luminaire provides a luminous flux of approximately 4550 to 4650 lumens with a power consumption of 34 watts and is available in colour temperatures of 3000 K (830) and 4000 K (840). With a UGR rating, it ensures glare-free lighting. The IP20/IP54 protection rating allows use in areas with varying requirements for touch and dust protection, while the impact resistance corresponds to IK02 class. Installation is as a recessed ceiling luminaire.

Tehnilised andmed

Half beam angle	90 °
Colour	white
Colour temperature	4000 Kelvin
Luminous Flux	4650 lm
electrical power	34 W
CRI	80
Net weight	1.94 kg
Installation depth	8 cm
Shape of cut-out	square
Installation length	57 cm
Installation width	57 cm
Height	2.8 cm
Length	59.5 cm
Width	59.5 cm
IP Code	IP20/IP54
Service life	70000 h
Luminous flux	4550 / 4650 lm
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	850 mA
Light outlet version	Down
Shape	square
Ambient temperature	-20 °C
Shock resistance category	IK02
Shock resistance	0.2 joule
Material	Aluminium
UGR ≤	19
Product name	PANEL C 600
CCT Switch	Yes
Assembly	Recessed
Risk group	0
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Ceiling lights, Indoor, Recessed
