The OCCULDAS 23 dimmable ceiling surface mounted light was designed exclusively by David Morgan and is fitted with a premium LED. The central trim ensures homogeneous, glare-free, atmospheric indirect lighting. Thanks to the built-in LED driver, the luminaire is suitable for direct connection to a 230V mains supply.

Tehnilised andmed

Half beam angle	120 °
Colour	white
Colour temperature	3000 Kelvin
Luminous Flux	1500 lm
electrical power	24 W
CRI	80
Net weight	1.879 kg
Diameter	23 cm
Height	8.5 cm
IP Code	IP20
Service life	30000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	700 mA
Dimming options	TRAILING_EDGE
Variant Dimm options	Trailing edge
Berker 2873 Result	Not compatible
Shock resistance category	IK02
Legrand PRO21 LED Dimmer 775659 Result	With restrictions
LK Fuga LED Dimmer 180 Touch Result	Not compatible
Material	Aluminium
LED can be changed	Exchange of lightsource only by professional
Product name	OCCULDAS 23
CCT Switch	No
DALI capable	No
Dimmable	Yes
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Niko 310-0190X Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions Assembly drawings REACh
Kategooriad	Ceiling lights, Indoor, LED, Surface mounted
