An all-round successful design with an elegant rectangular aluminium frame: the popular outdoor lights of the ESKINA family now offer even greater scope for application in the FRAME design alternative. The anthracite-coloured ESKINA FRAME makes a stylish impression in any outdoor area. The pivoting light heads ensure flexible light emission. Thanks to a high IP protection rating, ESKINA is perfectly protected from the elements. In addition, the light colour (3000/4000 K) can be selected using the CCT switch before installation. This means that easy installation is a mere formality.

Tehnilised andmed

Half beam angle	95 °
Colour	anthracite
Colour temperature	4000 Kelvin
Luminous Flux	2400 lm
electrical power	27 W
CRI	80
Net weight	3.285 kg
Height	75 cm
Length	11.5 cm
Width	7.3 cm
Beam angle	95 °
IP Code	IP65
Service life	30000 h
Luminous flux	2200 / 2400 lm
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	700 mA
Rotating or tilting	tiltable
Light outlet version	Spot 1
Plug type light	open cable end
Different light outlets	2
Seperate beams	Yes
Vertical tilting range	320 °
Vertical tilt range 2	320 °
Ambient temperature	-20 °C
Shock resistance category	IK06
Shock resistance	1 joule
Material	Aluminium
LED can be changed	Exchange of lightsource only by professional
Product name	ESKINA FRAME 75
CCT Switch	Yes
DALI capable	No
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Removal instructions Assembly drawings REACh
Kategooriad	Floor stand, LED, Outdoor
Sildid	CCT switch
