The THEO PRO S is a rectangular surface-mounted wall luminaire suitable for use in indoor and protected outdoor areas. It offers a combined up/down light distribution, which can be adjusted using an interchangeable reflector with a 10° beam angle. The luminaire features a DALI-2 dimming function and delivers a luminous flux of 600 lumens at 6 watts with a colour temperature of 2700 K. The housing is made of aluminium and has an IP65 protection rating as well as an IK06 impact resistance class, ensuring protection against dust, jet water, and mechanical impacts. With a compact design measuring 17.5 cm in height, 6.5 cm in width, and 10 cm in depth, the luminaire integrates flexibly into various architectural concepts.

Tehnilised andmed

Half beam angle	24 °
Colour	anthracite
Colour temperature	2700 Kelvin
Luminous Flux	600 lm
electrical power	6 W
CRI	80
Net weight	0.94 kg
Height	17.5 cm
Width	6.5 cm
Beam angle	24 °
IP Code	IP65
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	400 mA
Light outlet version	Top
Shape	rectangular
Glass temperature (light emission)	51 °C
Variant Dimm options	DALI
Different light outlets	2
Number of through-wires	15
Seperate beams	Yes
Ambient temperature	-25 °C
Shock resistance category	IK06
Shock resistance	1 joule
Material	Aluminium
Product name	THEO PRO S
CCT Switch	No
Dimmable	Yes
Assembly	Surface
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Assembly drawings REACh
Kategooriad	Indoor, Wall lights
