The NUMINOS® M SPOT surface-mounted ceiling luminaire is designed for indoor use and is particularly suitable for targeted accent lighting. It features a cylindrical shape and a matte black aluminium body combined with polycarbonate elements. With a luminous flux of 1750 lumens at 14 watts and a colour temperature of 2700 kelvin, it produces a warm white light. The beam angle is 36°, allowing for directed light distribution. The luminaire is equipped with phase-cut dimming and has an IP20 protection rating. Its dimensions are 18.5 cm in length, 8.5 cm in diameter, and 16.5 cm in height. The luminaire is intended for surface mounting on the ceiling and offers a declared service life of 50,000 hours.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	2700 Kelvin
Luminous Flux	1750 lm
electrical power	14 W
CRI	90
Net weight	0.834 kg
Diameter	8.5 cm
Height	16.5 cm
Length	18.5 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	350 mA
Dimming options	Trailing edge
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	Trailing edge
Different light outlets	1
Number of through-wires	78
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Berker 2873 Result	With restrictions
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® M
CCT Switch	No
DALI capable	No
Dimmable	Yes
Assembly	Surface
Risk group	1
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Jung 224 LED UDD Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Merten MEG5134-0000 Result	Compatible
Niko 310-0190X Result	Compatible
SLV 470807 Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Ceiling lights, Indoor, LED, Surface mounted
Sildid	Ceiling spot, LED ceiling light, TRIAC
