The NUMINOS® S PD pendant luminaire is designed for indoor use and is particularly suitable for direct lighting over tables or work surfaces. It features a cylindrical shape and a suspension length of 250 cm, allowing for flexible installation options. The luminaire operates at a power of 8 watts and produces a light colour of 3000 Kelvin with a beam angle of 36 degrees, ensuring targeted light distribution. The housing is made of aluminium and polycarbonate, providing a robust construction. The luminaire is equipped with PHASE-cut dimming, allowing for stepless brightness control. The IP20 protection rating makes it suitable for dry indoor environments. The round canopy and the slim diameter of 6.5 cm emphasise the understated design of the pendant luminaire.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	3000 Kelvin
Luminous Flux	1050 lm
electrical power	8 W
CRI	90
Net weight	0.82 kg
Diameter	6.5 cm
Height	16.2 cm
Pendant length	250 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	200 mA
Dimming options	Trailing edge
Shape	cylindrical
Variant Dimm options	Trailing edge
Different light outlets	1
Number of through-wires	128
Seperate beams	Yes
Ambient temperature	-20 °C
Berker 2873 Result	With restrictions
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® S
CCT Switch	No
DALI capable	No
Dimmable	Yes
Assembly	Surface
Risk group	1
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Jung 224 LED UDD Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Merten MEG5134-0000 Result	Compatible
Niko 310-0190X Result	Compatible
SLV 470807 Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Indoor, LED, Pendant lights
Sildid	Dimmable pendant light, TRIAC
