The NUMINOS® XL 3Ph. is a three-phase spotlight with a cylindrical design, intended for mounting on ceiling track systems. It is suitable for indoor use, for example in commercial or public areas where flexible and directional lighting is required. The spotlight delivers a luminous flux of 3500 lumens at a colour temperature of 4000 Kelvin and a beam angle of 60 degrees. The power consumption is 27 watts. The housing is made of aluminium and finished in matte black. Control is via DALI 2 and touch dimming. The spotlight has an IP20 protection rating and a declared service life of 50,000 hours. With a length of 20.8 cm, a diameter of 12 cm, and a height of 20 cm, the luminaire offers a compact design.

Tehnilised andmed

Half beam angle	60 °
Colour	black
Colour temperature	4000 Kelvin
Luminous Flux	3500 lm
electrical power	27 W
CRI	90
Net weight	1.549 kg
Diameter	12 cm
Height	20 cm
Length	20.8 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	700 mA
Dimming options	DALI and Touch
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	DALI and Touch
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Material	Aluminium
UGR ≤	22
Product name	NUMINOS® XL
CCT Switch	No
DALI capable	Yes
Dimmable	Yes
Assembly	Track
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	High voltage track systems, Indoor, LED, Other light source, Track systems
Sildid	Ceiling light, DALI, Downlight, Downlight recessed, Indoor lighting, LED spot, LED-Downlight, Recessed ceiling light, Recessed downlight, Spot
