The NUMINOS® XL 3Ph. DALI 3~ Spot is a cylindrical luminaire specifically designed for mounting on ceiling track systems. It is suitable for use in commercial and public indoor spaces where flexible and directional lighting is required. With a luminous flux of 3900 lumens at 27 watts and a colour temperature of 4000 Kelvin, the spot provides a neutral light colour and a beam angle of 36 degrees, enabling targeted illumination. The housing is made of aluminium and finished in matte black. The luminaire features DALI-2 and touch dimming, allowing comfortable and precise control of light intensity. The IP20 protection rating indicates that the luminaire is intended for use in dry indoor environments. Its compact design, with a length of 20.8 cm and a diameter of 12 cm, facilitates integration into various spatial concepts.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	4000 Kelvin
Luminous Flux	3900 lm
electrical power	27 W
CRI	90
Net weight	1.549 kg
Diameter	12 cm
Height	20 cm
Length	20.8 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	700 mA
Dimming options	DALI and Touch
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	DALI and Touch
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Material	Aluminium
UGR ≤	16
Product name	NUMINOS® XL
CCT Switch	No
DALI capable	Yes
Dimmable	Yes
Assembly	Track
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	High voltage track systems, Indoor, LED, Other light source, Track systems
Sildid	Ceiling light, DALI, Downlight, Downlight recessed, Indoor lighting, LED spot, LED-Downlight, Recessed ceiling light, Recessed downlight, Spot
