The NUMINOS® L CL, PHASE is a cylindrical surface-mounted ceiling light suitable for indoor use. It delivers a luminous flux of 2400 lumens with a colour temperature of 3000 Kelvin and a beam angle of 36 degrees. The luminaire features phase-cut dimming, allowing flexible light control. The housing is made of aluminium and measures 21.3 cm in height with a diameter of 10 cm. With an IP20 rating, it is suitable for dry, dust-free environments. Offering a lifespan of 50,000 hours, the luminaire provides a durable solution for general lighting in residential and commercial spaces.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	3000 Kelvin
Luminous Flux	2400 lm
electrical power	20 W
CRI	90
Net weight	1.018 kg
Diameter	10 cm
Height	21.3 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	500 mA
Dimming options	Trailing edge
Shape	cylindrical
Variant Dimm options	Trailing edge
Different light outlets	1
Number of through-wires	78
Seperate beams	Yes
Ambient temperature	-20 °C
Berker 2873 Result	With restrictions
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® L
CCT Switch	No
DALI capable	No
Dimmable	Yes
Assembly	Surface
Risk group	1
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Jung 224 LED UDD Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Merten MEG5134-0000 Result	Compatible
Niko 310-0190X Result	Compatible
SLV 470807 Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Ceiling lights, Indoor, LED, Surface mounted
Sildid	LED ceiling light, TRIAC
