The MEDO® RING 60 is a ROUND pendant luminaire featuring a suspension length of 300 cm, designed for indoor use. It offers a colour temperature range from 3000 to 4000 K and a beam angle of 110°, ensuring uniform illumination. The luminaire is equipped with PHASE-cut dimming, allowing flexible light control. Its housing is made of aluminium and steel, providing a robust and durable construction. With a diameter of 60 cm and a height of 7 cm, the luminaire presents a slim design. The IP20 rating makes it suitable for dry indoor environments. The MEDO® RING 60 is thus a technically advanced pendant luminaire for versatile lighting applications in residential and commercial spaces.

Tehnilised andmed

Half beam angle	110 °
Colour	black
Colour temperature	4000 Kelvin
Luminous Flux	4000 lm
electrical power	27 W
CRI	90
Net weight	3.82 kg
Diameter	60 cm
Height	7 cm
Pendant length	300 cm
IP Code	IP20
Service life	50000 h
Luminous flux	3750 / 4000 lm
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	700 mA
Light outlet version	Down
Shape	Round
Glass temperature (light emission)	29 °C
Variant Dimm options	Trailing edge
Number of through-wires	30
Ambient temperature	-20 °C
Material	Aluminium
UGR ≤	25
Product name	MEDO® RING 60
CCT Switch	Yes
Dimmable	Yes
Assembly	Surface
Berker 2873 Result	Compatible
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Jung 224 LED UDD Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Merten MEG5134-0000 Result	Compatible
Niko 310-0190X Result	Compatible
SLV 470807 Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Assembly drawings REACh
Kategooriad	Indoor, Pendant lights
