The KALU TRACK Spot is a high-voltage 3-PHASE spot for track systems, designed for indoor use. It is particularly suitable for flexible lighting solutions in commercial or private environments where targeted illumination is required. The spot features an LED light source with a colour temperature of 3000 K and a luminous flux of 970 lumens. The housing is made of aluminium and has a ROUND, white design. With dimensions of 13.5 cm length, 10.5 cm diameter, and 17 cm height, the spot is compactly designed. The IP20 protection rating allows use in dry indoor areas. Dimming is achieved via leading-edge and trailing-edge phase control, enabling flexible adjustment of light intensity. The spot is supplied with a 3-PHASE adapter and is part of the KALU product line.

Tehnilised andmed

Half beam angle	95 °
Colour	white
Colour temperature	3000 Kelvin
Luminous Flux	970 lm
electrical power	13 W
CRI	90
Net weight	0.498 kg
Diameter	10.5 cm
Height	17 cm
Length	13.5 cm
IP Code	IP20
Service life	25000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Rotating or tilting	rotary bar and tiltable
Light outlet version	Down
Horizontal rotation range	350 °
Variant Dimm options	leading edge and trailing edge dimmable
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Material	Aluminium
LED can be changed	Exchange of lightsource only by professional
Product name	KALU TRACK
CCT Switch	No
DALI capable	No
Dimmable	Yes
Energy label
Busch-Jäger 6523U Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Niko 310-0190X Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	3-Phase-System, High voltage track systems, Indoor, LED, Other light source, Track systems
Sildid	LED-Spotlight, Spotlight
