The new generation of the KADUX recessed ceiling light family features a robust light housing with a square design. The double-lamp recessed ceiling light emits an even more efficient, warm-white light (3,000 K) with a light output of 108 lm/W and extremely neutral, dimmable colour with a CRI of over 90. Ideal for use in shops, hotels and catering facilities. It is also quick and easy to install thanks to its direct connection to a 230V mains voltage.

Tehnilised andmed

Half beam angle	38 °
Colour	black/black
Variant Color 2	black
Colour temperature	3000 Kelvin
Luminous Flux	1550 lm
electrical power	14 W
CRI	90
Net weight	0.546 kg
Installation depth	8 cm
Shape of cut-out	square
Installation length	14 cm
Installation width	8 cm
Height	8.3 cm
Length	15 cm
Width	9 cm
Beam angle	38 °
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	350 mA
Rotating or tilting	tiltable
Shape	rectangular
Variant Dimm options	leading edge and trailing edge dimmable
Vertical tilting range	30 °
Vertical tilt range 2	30 °
Ambient temperature	-20 °C
Shock resistance category	IK02
Shock resistance	0.2 joule
Material	aluminium
Product name	KADUX
CCT Switch	No
Dimmable	Yes
Assembly	Recessed
Berker 2873 Result	Compatible
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Niko 310-0190X Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration REACh
Kategooriad	Ceiling lights, Indoor, Recessed
