Plain linear luminaires for a particularly elegant look: the IN-LINE spotlight is concealed within a 48V TRACK system, allowing only the best feature to surface: high-quality light with a 35° beam angle in various lumen, adjustable lighting colour via a CCT switch (2700 K/3000 K/4000 K) and natural colour reproduction (CRI >90). As a result, the DARKLIGHT REFLECTOR creates an atmosphere that particularly showcases restaurants, bars and hotels in a new light. The DALI-compatible and pivoting IN-LINE linear luminaires are also quick and easy to install via a track adapter.

Tehnilised andmed

Half beam angle	35 °
Colour	white/white
Variant Color 2	white
Colour temperature	3000 Kelvin
Luminous Flux	1230 lm
electrical power	14 W
Net weight	0.549 kg
Height	5.8 cm
Length	45.5 cm
Width	2.2 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	48V DC
Secondary power / secondary voltage	350 mA
Rotating or tilting	tiltable
Light outlet version	Direct
Variant Dimm options	DALI
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	180 °
Ambient temperature	-20 °C
Shock resistance category	IK02
Shock resistance	0.2 joule
Material	Aluminium
UGR ≤	16
Product name	IN-LINE 46
CCT Switch	No
Dimmable	Yes
Assembly	Track
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Indoor, Low voltage track, Track systems
