The LED Strip GRAZIA PRO FLEXSTRIP is suitable for a wide range of lighting applications where flexible and space-saving light solutions are required. The product is typically used indoors and offers a length of 5 metres with a width of 12 mm. The strip operates at a supply voltage of 24 V and features RGBW colour mixing for versatile lighting design. The housing is made of plastic with copper conductor tracks. The IP20 protection rating makes the strip suitable for dry environments. With a declared service life of 30,000 hours, the strip is designed for continuous lighting applications. The flat installation height of 2.2 mm allows for discreet mounting on various surfaces. The data refers to a colour temperature of 3000 K.

Tehnilised andmed

Half beam angle	120 °
Colour	white
Colour temperature	300 Kelvin
CRI	90
Net weight	0.133 kg
Height	0.22 cm
Length	500 cm
Width	1.2 cm
Colour consistency	6 SDCM
IP Code	IP20
Service life	30000 h
Primary nominal voltage	24V DC
Nominal voltage	24V DC
RGB	RGBW
Ambient temperature	-20 °C
Material	copper
Product name	GRAZIA PRO FLEXSTRIP
Minimal bend radius	3 °
CCT Switch	No
DALI capable	No
EEK LED strips	G
LED distance	1.4 cm
LEDs per separation section	70
Risk group	0
Length of cutting section	10 cm
Energy label
Tehnilised failid	Manual Datasheet CE declaration REACh
Kategooriad	Indoor, LED strips, RGB
Sildid	LED-Strip flexble, RGBW roll, RGBW strip
