The FRAME BASIC is an LED recessed wall light designed for indoor use. It features a square installation form and is specifically designed for integration into wall surfaces. The housing is made of aluminium and measures 9 x 9 cm with an installation depth of 5.5 cm. The luminaire emits warm white light at 2700 K and delivers a luminous flux of 170 lumens. With a service life of 60,000 hours, it provides a long-lasting lighting solution. The IP20 protection rating makes it suitable for dry indoor areas. Installation is carried out using leaf springs, ensuring easy mounting.

Tehnilised andmed

Colour	gray
Colour temperature	2700 Kelvin
Luminous Flux	170 lm
electrical power	3 W
CRI	90
Net weight	0.271 kg
Installation depth	6.5 cm
Shape of cut-out	square
Installation length	7.2 cm
Installation width	8 cm
Length	9 cm
Width	9 cm
IP Code	IP20
Service life	60000 h
Primary nominal voltage	100-240V ~ 50/60Hz
Secondary power / secondary voltage	350 mA
Ambient temperature	-20 °C
Material	Aluminium
LED can be changed	Exchange of lightsource only by professional
Product name	FRAME BASIC
CCT Switch	No
DALI capable	No
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Indoor, LED, Recessed, Wall lights
Sildid	Staircase lighting
