The FIX-IT! 48V Spot is a ROUND spotlight for ceiling track systems with a standard 48V surface-mounted track, particularly suited for indoor use. It delivers a luminous flux of 850 lumens at 6.6 watts with a colour temperature of 3000 K, providing a pleasant, warm white light. The beam angle is 36°, allowing for targeted illumination. The housing is made of aluminium and polycarbonate, ensuring a robust construction. The luminaire features a black insert and measures 7 cm in diameter with a height of 8.2 cm. Control is via DALI 2, enabling flexible dimming options. The IP20 protection rating is designed for indoor environments. This luminaire is designed for use with standard ceiling track systems and offers a declared service life of 50,000 hours.

Tehnilised andmed

Half beam angle	36 °
Colour	black/black
Variant Color 2	black
Colour temperature	3000 Kelvin
Luminous Flux	850 lm
electrical power	6,6 W
CRI	90
Net weight	0.2 kg
Diameter	7 cm
Height	8.2 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	48V DC
Secondary power / secondary voltage	175 mA
Shape	round
Variant Dimm options	DALI
Different light outlets	1
Seperate beams	Yes
Ambient temperature	-20 °C
Material	Aluminium
UGR ≤	16
Product name	FIX-IT!
CCT Switch	No
Dimmable	Yes
Assembly	Track
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	Ceiling lights, Indoor, Low voltage track, Track systems
