The BATTEN P is a surface-mounted wall and ceiling luminaire suitable for indoor use. It features a rectangular aluminium housing measuring 120 cm in length, 5.6 cm in width, and 6.5 cm in height. The luminaire offers a light output ranging from 2985 to 5000 lumens and is available in various colour temperatures (830, 840, 850). With an IP20 rating and impact resistance class IK04, it is designed for protected indoor areas. The luminaire is equipped with a motion sensor (PIR) and has a declared service life of 100,000 hours.

Tehnilised andmed

Colour	white
Colour temperature	5000 Kelvin
Luminous Flux	5000 lm
electrical power	20 W
CRI	80
Net weight	0.75 kg
Height	6.5 cm
Length	120 cm
Width	5.6 cm
IP Code	IP20
Service life	100000 h
Luminous flux	2985 - 5000 lm
Primary nominal voltage	220-240V ~ 0/50/60Hz
Secondary power / secondary voltage	200-350mA
Shape	rectangular
TC point (°C)	80 °C
Ambient temperature	-20 °C
Shock resistance category	IK04
Product name	BATTEN P 1200 52 830/840/850
CCT Switch	Yes
Assembly	Surface
Risk group	1
Tehnilised failid	Manual Datasheet CE declaration REACh
Kategooriad	Ceiling lights, Indoor, Surface mounted
