The NUMINOS® M 3Ph. is a cylindrical 3-phase spotlight for the ceiling track system, designed for indoor use. With a luminous flux of 1950 lumens at 14 watts and a colour temperature of 4000 K, it provides a neutral light colour and a beam angle of 36°. The housing is made of aluminium and finished in matt black. The luminaire features trailing edge phase-cut dimming and is rated IP20 for protection against contact and solid foreign objects. Its compact dimensions of approximately 18.5 cm in length, 8.5 cm in diameter, and 15.5 cm in height allow for flexible integration into various interior lighting applications. The declared service life is 50,000 hours.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	4000 Kelvin
Luminous Flux	1950 lm
electrical power	14 W
CRI	90
Net weight	0.797 kg
Diameter	8.5 cm
Height	15.5 cm
Length	18.5 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	350 mA
Dimming options	Trailing edge
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	Trailing edge
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Berker 2873 Result	With restrictions
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® M
CCT Switch	No
DALI capable	No
Dimmable	Yes
Assembly	Track
Risk group	1
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Jung 224 LED UDD Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Merten MEG5134-0000 Result	Compatible
Niko 310-0190X Result	Compatible
SLV 470807 Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	3-Phase-System, High voltage track systems, Indoor, LED, Other light source, Track systems
Sildid	LED power track spotlight, LED shop lighting, Shop lighting, TRIAC
