The NUMINOS® L 3Ph. is a cylindrical 3-PHASE spotlight designed for mounting on ceiling track systems. It is particularly suitable for indoor use where targeted lighting is required. The spotlight has a power output of 20 watts and produces a luminous flux of 2600 lumens at a colour temperature of 4000 Kelvin. The beam angle is 36 degrees, allowing for focused light distribution. The housing is made of aluminium and finished in matte black. With a length of 21.3 cm, a diameter of 10 cm, and a height of 17 cm, the luminaire is compactly designed. Dimming is performed via phase-cut (trailing edge). The protection rating is IP20, intended for use in dry indoor environments.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	4000 Kelvin
Luminous Flux	2600 lm
electrical power	20 W
CRI	90
Net weight	1.097 kg
Diameter	10 cm
Height	17 cm
Length	21.3 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	500 mA
Dimming options	Trailing edge
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	Trailing edge
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Berker 2873 Result	With restrictions
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® L
CCT Switch	No
DALI capable	No
Dimmable	Yes
Assembly	Track
Risk group	1
Busch-Jäger 6523U Result	Compatible
Eltako EUD 61 NPN-UC Result	Compatible
Jung 224 LED UDD Result	Compatible
Legrand PRO21 LED Dimmer 775659 Result	Compatible
LK Fuga LED Dimmer 180 Touch Result	Compatible
Merten MEG5134-0000 Result	Compatible
Niko 310-0190X Result	Compatible
SLV 470807 Result	Compatible
Tehnilised failid	Manual Datasheet CE declaration Removal instructions REACh
Kategooriad	3-Phase-System, High voltage track systems, Indoor, LED, Other light source, Track systems
Sildid	LED power track spotlight, LED shop lighting, Shop lighting, TRIAC
