The NUMINOS® S 3Ph. DALI 3~ Spot is a cylindrical spotlight designed for mounting on ceiling or wall track systems. It is suitable for indoor use, for example in commercial or public areas where directional lighting is required. With a power consumption of 7.8 watts, the spot produces a luminous flux of 1100 lumens at a colour temperature of 4000 K and a beam angle of 36°. The housing is made of aluminium and finished in matte black. Control is via DALI 2 and touch dimming. The spot measures 16.2 cm in length, has a diameter of 6.5 cm, and a height of 14.5 cm. The IP20 rating provides protection against contact and solid foreign objects larger than 12.5 mm. The declared service life is 50,000 hours.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	4000 Kelvin
Luminous Flux	1100 lm
electrical power	7,8 W
CRI	90
Net weight	0.579 kg
Diameter	6.5 cm
Height	14.5 cm
Length	16.2 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	200 mA
Dimming options	DALI and Touch
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	DALI and Touch
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® S
CCT Switch	No
DALI capable	Yes
Dimmable	Yes
Assembly	Track
Risk group	1
