The NUMINOS® M 3Ph. DALI 3~ Spot is a cylindrical spotlight designed for mounting on ceiling track systems. It is suitable for indoor use, for example in commercial or public areas where targeted lighting is required. The spot delivers a luminous flux of 1750 lumens at 13 watts with a colour temperature of 2700 Kelvin, producing warm white light. The beam angle is 36 degrees, ensuring focused light distribution. The housing is made of aluminium with a matt black finish. With an IP20 rating, the product is protected against solid foreign objects larger than 12.5 mm but not against moisture. Control is via DALI 2 and touch dimming, allowing flexible light regulation. The compact design, with a length of 18.5 cm and a diameter of 8.5 cm, facilitates integration into various lighting systems.

Tehnilised andmed

Half beam angle	36 °
Colour	black
Colour temperature	2700 Kelvin
Luminous Flux	1750 lm
electrical power	13 W
CRI	90
Net weight	0.833 kg
Diameter	8.5 cm
Height	16.5 cm
Length	18.5 cm
IP Code	IP20
Service life	50000 h
Primary nominal voltage	220-240V ~ 50/60Hz
Secondary power / secondary voltage	350 mA
Dimming options	DALI and Touch
Shape	cylindrical
Horizontal rotation range	350 °
Variant Dimm options	DALI and Touch
Different light outlets	1
Seperate beams	Yes
Vertical tilting range	90 °
Ambient temperature	-20 °C
Material	Aluminium
UGR ≤	16
LED can be changed	Control gear replaceable by a professional
Product name	NUMINOS® M
CCT Switch	No
DALI capable	Yes
Dimmable	Yes
Assembly	Track
Risk group	1
